bcp 1.25G 1550nm EX SFP transceiver is designed to transmit and receive optical data over Single mode optical fiber for link length 40km.
| Transceiver | |
| Form Factor | SFP |
| Wavelength | 1550nm |
| Connector | Duplex LC |
| Transmitter Type | DFB |
| Transmitter output power | -5.0~+0.0dBm |
| Typical Power Consumption | <700mW |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Industrial Temperature Range | -40 to 85°C (-40 to 185°F) |
| Vendor Name | bcp |
| Max Data Rate | 1.25Gbps |
| Max Cable Distance | 40km |
| Media | SMF |
| Receiver Type | PIN |
| Receiver Sensitivity | < -25dBm |
| Extinction Ratio | 9dbM |
